5 Port Gigabit Ethernet Switch, Four 10/100/1000Base-T and One 1000Base-X Optical

Description

Looking for a reliable, high-performance network switch that combines the convenience of copper connections with the reach of fiber optics? The Baudcom BD-1000M-4TX 5-Port Gigabit Ethernet Switch is the perfect hybrid solution for expanding and future-proofing your business or industrial network. Equipped with one fixed 1000Base-FX fiber optic port and four 10/100/1000Base-T UTP RJ-45 ports, this reliable switch eliminates the limitations of CAT5e UTP cables and extends your network’s range. Provides full-duplex mode for high-speed data transfer or half-duplex in 10/100M mode, giving you flexibility based on your network’s needs.

Designed for ease of use with no software configuration required. It’s the ideal media converter and network switch combo for extending a reliable, high-speed Gigabit connection from your core network to remote offices, separate buildings, or industrial control rooms far beyond the 100-meter limit of standard CAT5e cable.

5 Port Gigabit Ethernet Switch Features

Exceptional Long-Distance Connectivity: Overcome the limitations of UTP cable. The fiber port supports transmission distances up to 100 kilometers with single-mode fiber, making it perfect for campus networks, traffic monitoring systems, or remote security installations.

Plug-and-Play Operation: Designed for ease of use with no software configuration required. The switch supports auto-negotiation on RJ-45 ports for optimal speed (10/100/1000Mbps) and IEEE 802.3x flow control for reliable, lossless data transmission, ensuring stable network performance right out of the box.

Full Duplex / Half Duplex: Supports full-duplex operation for 10/100/1000Mbps. Half-duplex operation is available only in 10/100M mode, providing flexibility for varying network speeds.

Robust and Reliable Build: Built for demanding environments with a wide operating temperature range of 0°C to +55°C. It features a universal AC power input (100-240V), ensuring consistent operation in server rooms, telecom closets, or industrial settings.

•  1000Base-SX/LX/ZX standards
•  Transfer fiber: multimode (50/125, 62.5/125 or 100/140um); single mod (8.3/125, 8.7/125, 9/125 or 10/125um)


1000Base-FX Optical interface:

•  Connector: SC, FC or ST are optional
•  Wavelength: 1310nm,1550nm or 850nm(can be chosen by customer)
•  Optical fiber category:

         single-mode 8.3/125, 8.7/125, 9/125, 10/125um

        multi-mode 50/125, 62.5/125, 100/140um

•  multi- mode connection: transmitting range can reach 5 kilometers as farthest
•  single-mode connection: transmitting range can reach 100 kilometers.

10/100/1000Base-TX

•  Connector: UTP RJ45 connector
•  Data Rates:

        10/100/1000Mbps(802.3 10Base-T/802.3u 100Base-T)

        100Mbps (100Base-FX)
